Rotational switches B = 8:
- monitored zone access, manual start
- protective devices on S11-S14 always active
- protective device on S21-S24 always active, when control contact on
charger (S32) is closed
- remote control active, when control contact on S32 is open
- zone protection can be disabled for a certain time with remote control
-t
max.
Adjustable monitoring time with rotational switch A
reset of all failures with hardwired start button or start button on remote
control (+infra red)
disconnection from S12-14 or S22-S24 when control contact S32 is open:
see Function diagram of rotational switch B=0
2.11.2 Function Diagrams
Rotational switches B = 8:
- monitored zone access, manual start
- protective devices on S11-S14 always active
- protective device on S21-S24 always active, when control contact on
charger (S32) is closed
- remote control active, when control contact on S32 is open
- zone protection can be disabled for a certain time with remote control
-t
max.
Adjustable monitoring time with rotational switch A
reset of all failures with hardwired start button or start button on remote
control (+infra red)
disconnection from S12-14 or S22-S24 when control contact S32 is open:
see Function diagram of rotational switch B=0
2.11.2 Function Diagrams
