Failure and status indication of the radio receiver
The status of the safety radio receiver is indicated by flashing codes (No) of the red LED
”receiver error” and the green LED “reception”.
Red LED “receiver error”
No. Status Mode Description
OFF No radio signal
OFF Message with valid identity code
Symmetric
Normal operation
Message with invalid identity code
flashing
ON
Serial
Writing parameters and reading data
connection
2 Supply
3 Safe connection to administrator part
4 Flashing with
Error
EEPROM
5 failure code RAM
6 ROM
7 Processor type
Failure and status indication of the radio receiver
The status of the safety radio receiver is indicated by flashing codes (No) of the red LED
”receiver error” and the green LED “reception”.
Red LED “receiver error”
No. Status Mode Description
OFF No radio signal
OFF Message with valid identity code
Symmetric
Normal operation
Message with invalid identity code
flashing
ON
Serial
Writing parameters and reading data
connection
2 Supply
3 Safe connection to administrator part
4 Flashing with
Error
EEPROM
5 failure code RAM
6 ROM
7 Processor type
