7
TECHNICAL DATA MS-24 U
Model MS-24 U
Engine model 1E34F
Engine displacement 24.5 cm³
Maximum engine performance 0.73 kW max.
Engine speed at recommended max.
9,700/min max. (Blade)
8,200/min max. (String-head)
Cutting Width:
230 mm (Blade)
430 mm (String-head)
Idling speed 3,000/min ± 100/min
Clutch engagement speed 4,100/min ± 300/min
Gear ratio 14/19
Fuel
Mixed gas
Gasoline: Two-stroke Engine Oil = 50:1
Volume (fuel tank) 0.5 L
Vibration (tested according to ISO 22867): Max. a
h
= 4.599 m/s
2
K = 1.5 m/s
2
Noise (tested according to ISO 22868):
Max. sound pressure values (operator position): L
pA
: 96.70 dB (A); K
pA
= 2.5 dB (A)
Max. sound power values: L
wA
: 108.93 dB(A); K
wA
= 2.5 dB (A)
Noise (tested according to 2000/14/EC, amended by 2005/88/EC):
Max. guaranteed sound power values
L
wA
: 114 dB (A)
Mass (without plastic guard and cutting blade) 4.5 kg
