30Repair Manual PS-6400/PS-7300/PS-7900
1
2
4
3
(1,0 Nm + 0,5)
08 CARBURETOR
Induction channel
The carburetor and the manifold are screwed to the
flange ring 2 with two 2 screws 3 (M4 x 55) with
countersunk square nut 1.
During assembly, tighten screws 3 only to 1.0 Nm +
0.5.
CAUTION: Don’t forget the bushing 4!
Tool
(1.0 Nm + 0.5)
