42Repair Manual PS-6400/PS-7300/PS-7900
14 TORQUES
Ground wire Slotted.BZ 3.5 x 9.5 1 x 1.5 +/- 0.2
Ignition fastening in crankcase Torx M 4 x 20 2 x 5 – 0.5
Flywheel fastening with nut M 8 x 1 1 x 27 +/- 2
Starter housing on crankcase Torx M 5 x 20 3 x 4 + 1
Protective hood / base on crankcase Torx M 5 x 20 2 x 6 +/- 0.5
Hand guard bearing, magneto-side Torx M 5 x 20 1 x 4 + 0.5
Hand guard bearing, clutch-side Torx M 5 x 20 1 x 4 + 0.5
Spike bar, crankcase, top Torx M 5 x 12 1 x 12 +/- 0.5
Spike bar / Chain catch, crankcase, bottom Torx M 5 x 16 1 x 12 +/- 0.5
Spike bar sprocket guard Torx M 5 x 12 2 x 10+/- 0.5
Chain tensioning housing Slotted.BZ 3.5 x 9.5 1 x 1.5 +/- 0.2
Grip shell / tank Torx M 4 x 20 1 x 4 +/- 0.5
Tubular handle Torx 5.5 x 20 4 x 5 +/- 0.5
Damping spring cap attachment ——— 3 7.5 +/- 0.5
Damping spring / tank, clutch- and magneto-side, rear Torx 5.5 x 20 2 x 5 +/- 0.5
Damping spring / tank, clutch-side, forward Torx 6.7 x 30 1 x 6 +1
Tubular handle clamp / damper on cylinder Torx M 6 x 14 1 x 6 +/- 0.5
Induction hose clamp Cross-slot M 3 1 x 0.5 – 0.2
Spark clamp attachment ——— 1 x 25 +/-5
Cable drum in fan housing Torx 5.5 x 20 1x 4.5 +/-1
Generator armature in crankcase Torx 4 x 20 3 x 4 + 1
