Dolmar PS-6400 - Starter Motor and Recoil System; Starter Housing and Induction Channel

20Repair Manual PS-6400/PS-7300/PS-7900
1 (4,0 Nm + 1,0)
4,5 Nm ± 1,0
2
06 STARTER
Starter
The fan housing is bolted onto the crankcase with 3
Torx/slotted screws 1 (M5x20).
Induction channel
The air duct 2 guides the inducted cool air to the
cylinder for proper operation.
Tool
(4.0 Nm + 1.0)
4.5 Nm ± 1.0
