ES
Conexión del aparato MCA1215 – MCA2440
112
8.4 Asignación de terminales
Los terminales de la clavija bus TEMP/LIN1 se distribuyen de la siguiente forma:
Los terminales de la clavija bus LIN2 se distribuyen de la siguiente forma:
Term inal en
fig. 7, página 6
Asignación
1 R_VCC
2GND
3TEMP
4BAT –
5 LIN BUS DATA I/O
6BAT +
Term inal en
fig. 7, página 6
Asignación
1 R_VCC
2BAT –
3NC
4BAT –
5 LIN BUS DATA I/O
6BAT +
MCA1215-2440--IO-16s.book Seite 112 Freitag, 11. November 2016 9:15 21
