Connecting the device MCA1215 – MCA2440
20
8 Connecting the device
8.1 Connecting to battery and power supply
Connecting the battery
Observe the following instructions when connecting the battery:
!
• Make sure the battery terminals are clean when connecting them.
• Make sure the plug connector is fitted securely.
• Select a connection cable with a sufficient cross-section (see chapter “Technical
data” on page 31).
• Lay the cables in accordance with VDE°100 (Germany).
• Connect the negative cable directly to the negative terminal of the battery, and
not to the chassis of a vehicle or boat.
• Use the following cable colours:
– Red: positive connection
– Black: negative connection
• Do not reverse the polarity. Reversing the polarity can cause damage to the
device.
➤ Lay the positive cable from the battery charger to the positive terminal of the
battery and connect it.
➤ Lay the negative cable from the battery charger to the negative terminal of the
battery and connect it.
Connecting the 230 V power supply
➤ Plug the 230 V connection cable included in the delivery into the MCA battery
charger‘s “AC INPUT” socket.
➤ Connect the device with the he 230 V connection cable to a 230 V socket which
is protected by a residual current circuit breaker.
CAUTION!
• Avoid coming into contact with the battery fluid.
• Batteries with a cell short circuit may not be charged, as explosive
gases may form due to overheating of the battery.
MCA1215-2440--IO-16s.book Seite 20 Freitag, 11. November 2016 9:15 21
