MCA1215 – MCA2440 Technical data
31
14 Technical data
General technical data
MCA12xx, MCA24xx
Battery types: Lead-acid, gel, AGM, Li-Ion
Heat dissipation: Fan
Charge mode: 5-level
Maximum ambient temperature: –20 °C – +50 °C
Storage temperature: –40 °C – +85 °C
Air humidity: 20 – 90 %
Temperature coefficient: ±0.03%/°C (0 – 50°C)
Temperature compensation (MCA12xx)
Temperature compensation (MCA24xx):
–20 mV/°C (battery sensor)
–40 mV/°C (battery sensor)
Vibration: 10 – 500 Hz
2 g for 10 min/cycle within 60 minutes for X, Y and
Z axis
Voltage insulation: I/P – O/P: 4 kVw
I/P – FG: 1.7 kVw
O/P – FG: 0.7 kVw
Insulation resistance: I/P – O/P: 100 MΩ/500 Vg
Alarm signal: via relay contact
Communication: via LIN-BUS
Sleep mode (noise-reduced mode): via remote control (accessory) or DIP switch
Remote control (accessory): On/off switch, three-colour LED, sleep mode
option
Testing/certification:
MCA1215-2440--IO-16s.book Seite 31 Freitag, 11. November 2016 9:15 21
