Connecting the device MCA1215 – MCA2440
22
Charging using the battery management system PerfectControl MPC01
(accessory) (12 V only)
➤ Set the DIP switches 1 to 3 on the MCA battery charger to “ON” (chapter “Setting
the DIP switches” on page 24).
You can find detailed information in the operating manual for MPC01.
Charging using the remote control MCA-RC1 (accessory)
I
➤ Insert one end of the RJ-11 cable into the socket (fig. 0 3, page 7) of the
MCA-RC1.
➤ Insert the other end of the RJ-11 cable into the TEMP/LIN1 socket on the MCA
battery charger.
8.3 Wiring diagrams
Example of a wiring diagram, 12 V: see fig. 5, page 6.
Example of a wiring diagram, 24 V: see fig. 6, page 6.
NOTE
The length of the RJ-11 cable may not exceed 7 m.
No. in
fig. 5, page 6
Explanation/function
1 MCA charger
2Consumer
3 PerfectControl MPC01
4 12 V battery sensor IBS
5 12 V battery
6Fuse
7 Starter battery
No. in
fig. 6, page 6
Explanation/function
1 MCA charger
2 12 V battery
3 Starter battery
MCA1215-2440--IO-16s.book Seite 22 Freitag, 11. November 2016 9:15 21
