MCA1215 – MCA2440 Connecting the device
25
➤ Use the DIP switches (fig. a page 7) to set the required functions and values:
– To set the switchover voltage:
– To set the retention voltage:
– To set the power mode:
– Enabling the control for external devices (such as MPC01, does not apply to
MCA-RC1):
– To activate sleep mode:
Switch 1 Switch 3 Switchover voltage
ON OFF 14.4 V / 28.8 V
OFF OFF 14.7 V / 29.4 V
Switch 2 Switch 3 Retention voltage
ON OFF 13.5 V / 27.0 V
OFF OFF 13.8 V / 27.6 V
Switch 1 Switch 2 Switch 3 Constant voltage
MCA12.. MCA24..
OFF OFF ON 13.2 V 26.4 V
OFF ON ON 13.8 V 27.6 V
ON OFF ON 14.4 V 28.8 V
Switch 1 Switch 2 Switch 3
ON ON ON
Switch 4
ON
