SK
Pripojenie prístroja MCA1215 – MCA2440
392
8.3 Schémy zapojenia
Príklad schémy zapojenia 12 V: pozri obr. 5, strane 6
Príklad schémy zapojenia 24 V: pozri obr. 6, strane 6
Pol. na
obr. 5, strane 6
Vysvetlenie/Funkcia
1 MCA nabíjačka
2 Spotrebič
3 PerfectControl MPC01
4 12 V senzor batérie IBS
5 12 V batéria
6Poistka
7 Štartovacia batéria
Pol. na
obr. 6, strane 6
Vysvetlenie/Funkcia
1 MCA nabíjačka
2 12 V batéria
3 Štartovacia batéria
