FR
Raccordement de l’appareil MCA1215 – MCA2440
82
8.4 Affectation des broches
Les broches de la prise bus TEMP/LIN1 sont affectées comme suit :
Les broches de la prise bus LIN2 sont affectées comme suit :
Broche dans
fig. 7, page 6
Affectation
1 R_VCC
2GND
3TEMP
4BAT
5 LIN BUS DATA I/O
6BAT +
Broche dans
fig. 7, page 6
Affectation
1 R_VCC
2BAT
3NC
4BAT
5 LIN BUS DATA I/O
6BAT +
