Domino F Series User Manual

OPERATION
3-50 EPT031055 Issue 2 September 2017
Standard Parameters
Default Parameters
Parameter Ranges
Parameter Laser System
F720 i-Tech 10mm scan head
Simmer Current 75%
Waveform 0
StepPeriod [μs] 10
JumpDelay [μs] 70
MarkDelay [μs] 70
PolygonDelay [μs] 10
LaserOffDelay [μs] 130
LaserOnDelay [μs] 90
OnPulse 1
Period 14.2857 [70kHz]
MaxVectorLength [mm] 0.2
JumpSpeed [bit/ms] 6000
MarkSpeed [bit/ms] 4000
Parameter Laser System
F720 i-Tech 10mm scan head
StepPeriod [μs] 10..100
JumpDelay [μs] 0..500
MarkDelay [μs] 0..500
PolygonDelay [μs] 10..500
LaserOffDelay [μs] 10..500
LaserOnDelay [μs] 0..500
MaxVectorLength [mm] 0..100
JumpSpeed [bit/ms] 1000..13000
MarkSpeed [bit/ms] 10..17000
