OPERATION
3-12 EPT009665 Issue 2 May 2015
SWITCHING ON AND OFF
WARNINGS: (1) The laser marking system must only be used for
its intended purpose.
(2) The laser marking system may only be operated
by trained personnel.
(3) Operation is only allowed with all required cables
connected and all parts mounted.
Do not disconnect any cables during operation.
(4) Refer also to PART 1 : “HEALTH & SAFETY” .
CAUTION: The lens cap, used to prevent damage or external
soiling that will cause a reduction in laser
performance, must be removed before operation.
Switching On the Control Unit
At the F220i Laser unit, turn the switch from position "0" to position "1".
At the BCP7 controller, release the On/Off button by turning it clockwise.
Wait until the SERVER RUNNING indicator has illuminated.
Switching On the Laser Head
Turn the key switch from position "0" to position "1". To start the laser turn
the key clockwise to the laser symbol and hold it for at least 1 second. The
key automatically turns back to position "1".
(a) The laser needs a warm-up phase of 3 seconds.
The PRINTER BUSY indicator will illuminate when the laser
hardware is switched on.
The PRINTER READY indicator illuminates. After initialising the
Dynamark 4 software and starting the lasers, the marking system is ready.
Laser emission is also displayed by a red LED on the rear of the laser unit.
