OPERATION
3-52 EPT009665 Issue 2 May 2015
Waveform
The fibre laser system has a range of pulse repetition frequencies from 1
kHz up to 1000 kHz.
The laser will fire a pre programmed waveform, which defines the temporal
shape of the laser pulse. The system with adjustable waveforms has 25
different types available as shown in the table below.
Waveform
[Number]
Approx.
Duration [ns]
PRF
0
[kHz]
E
max
[mJ]
0 200 25 0.8
165650.31
2 30 125 0.16
3 15 250 0.08
4 12 375 0.053
595000.04
6
Repetition of waveforms
7
8
9
10
11 200 25 0.8
12 190 26 0.77
13 180 27 0.74
14 170 28 0.71
15 160 29 0.69
16 150 30.5 0.66
17 140 32 0.63
18 130 33.5 0.6
19 120 35.5 0.56
20 110 38 0.53
21 100 41 0.49
22 90 45 0.44
23 80 50 0.4
24 70 57 0.35
25 60 66 0.3
26 50 78 0.26
27 40 97 0.21
28 30 135 0.15
29 20 250 0.08
