PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
PSS 5000 CPU Board
specifications
The product specifications for the CPU boards of the PSS 5000 are presented
in the table below:
Note: When upgrading from a CPB50x system to a CPB539, if the LON
KIT422 is in use, it is necessary to substitute it by installing a DSB522
with the CPB539.
Note: 411 software applications require a CPB509 or CPB505-2. 410 software
applications run on all CPB50x systems. 452 software applications re-
quire a CPB539.
4.1.1 KIT453 – CPB50x to CPB539
LON interface When upgrading a PSS 5000 system using KIT453, it is necessary to note
whether the LON KIT422 is in use. If it is, then it is necessary to supplement
the CPB539 with a DSB522, which will provide the necessary LON function-
ality.
Parameters
CPU Board Version
CPB505-2 CPB509 CPB539
CPU Specs
CPU Type ColdFire MCF5307 ColdFire MCF5307 ARM
Flash 16 MB 16 MB 4 – 256 GB
SRAM 4 MB 4 MB 1 – 4 GB
Real-time Clock Yes Yes Yes
Port Types and Number
DSB 3
5
1
6
DMB 1
3
1
2
Ethernet 1 1 2
Service (RS232)
0
2
10
Extension Socket
(LON - FTT10)
1 (option) 1 (option) 0
1
: one of the ports is a high-speed port
2
: The boot program only supports PPP on the Service port. Software uploads on boards with no Service port
must take place via the Ethernet port.
*: At a power outage, the system is closed systematically and the data is stored in a non-volatile memory.
