PSS5000/CONF/804473/40 25 of 54
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
3.4 Washing Machine Protocols and HIMs
Washing machine
protocol and associated
HIM
The washing machine protocol and the HIM associated with it is shown in the
table below:
3.5 Vapor Recovery Monitoring Controller Protocols and HIMs
Vapor recovery protocol
and associated HIM
The vapor recovery protocol and the HIM associated with it is shown in the
table below:
Prowalco Remote Tagging
ZA-069 (IRIU)
Current Loop, 45mA DSB492 140042 255
DSB511 142464
Current Loop, 40mA DSB503 142061 255
Tokheim DAC MPA V5 Ethernet n/a n/a 99
Tokheim Pump Tag Current Loop, 20mA DSB408 Replaced 16
DSB520 143357
Wayne CL Terminal Current Loop, 40mA DSB415 Replaced Cards: 16
Notes: 4
Current Loop, 30mA DSB475 136841
Wayne CL/EPS-42 Terminal RS422 (with echo canceling) DSB475 136841 16
Protocols Interface Type HIM Stock No. Devices/Port
Protocols Interface Type HIM Stock No. Devices/Port
IFSF Car wash LON (TP/FT-10) ‡ DSB522 143576 16
‡ Only one LON (TP/FT-10) interface (i.e. 1xKit422 or 1xDSB522) can be in-
stalled on each system.
Protocols Interface Type HIM Stock No. Devices/Port
Fafnir DVRC RS485 DSB453 133768 32
DSB501 142012 32
Fafnir DVRC-2 RS485 DSB453 133768 32
DSB501 142012 32
