18 of 54 PSS5000/CONF/804473/40
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
3.1 Pump Protocols and HIMs
List of pump protocols
and associated HIMs
A complete list of the pump protocols currently supported by the PSS 5000
and the HIMs associated with the protocols and interface types are shown in
the table below:
Note: Where Devices in Devices/Port refers to the number of fuelling points
that can be connected to each port on the CPB.
Protocols Interface Type HIM Stock No. Devices/Port
Adast Easycall RS485 DSB453 133768 16
DSB501 142012
Aplab Serial protocol RS485 DSB453 133768 16
DSB501 142012
Auto Tank ATCL Current Loop, 10/20mA DSB416 129767 8
Avery Single Hose RS485 DSB453 133768 16
DSB501 142012
BP Standard Protocol RS232 DSB347 123240 40
Bennett Current Loop 20mA DMB425 130742 16
Cetil EAS1 RS485 DSB453 133768 16
DSB501 142012
Dong Hwa Prime RS422 DSB352 125775 16
Dresser Wayne SC82/SC86 Current Loop, 30mA
DSB423
1
130250 24
DSB475 136841
DSB510 142390
RS485 DSB453 133768
Droher-Condohr Protocol RS485 DSB337 Replaced 24
DSB501 142012
Droher-Current Loop Protocol Current Loop, 20mA DSB356 Replaced 16
DSB517 143186
Dunclare Current Loop, 20mA DMB431 Replaced 16
DMB507 142346
EIN Current Loop, 20mA DSB476 137571 16
ELREM Tank2000 RS485 DSB453 133768 16
EMR3 RS232 (with carrier detect) DSB347 123240 31
RS232 (3-wire) DSB457 133845
EnE RS485 DSB453 133768
Gascomm 2-wire, active pull down DMB514 143076 16
