PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
3.7 Interface Types and HIMs
List of Interfaces with
associated HIMs
The table below provides a complete list of the currently supported interface
types and their associated HIMs. This list can be used to determine whether
development for a new HIM is required when support for a new protocol is be-
ing planed.
Note: DSB modules are used for protocols that have addressable devices.
DMB modules are used for protocols that have non-addressable devic-
es.
Note: When more than one module is available for an interface type, use the
hyperlink to look at the module properties for more information. Nor-
mally, the only difference is the number of connectors present on the
modules.
Interface Type
Modules
Addressable Non-addressable
2-wire C-bus DSB340 n/a
2-wire, active pull down n/a DMB514
4-wire Diff. interface DSB541 n/a
Diff. interface with auto-
watch
n/a DMB512
Current Loop 4-wire, 10mA (active) n/a DMB450
4-wire, 10/20mA DSB411
DSB416
n/a
4-wire, 30mA DSB475 n/a
4-wire, 40mA (active) DSB503 n/a
4-wire 24V/50mA (active) n/a DMB426
3-wire, 20mA (passive) DSB520 n/a
3-wire, 20mA (active) DSB461
DSB476
n/a
2-wire, 20mA (passive) DSB486 DMB507
2-wire, 20mA (active) DSB517 DMB425
2-wire, 20mA (active) with
RX inverted
DSB542 n/a
2-wire, 12V/25mA (active) n/a DMB489
2-wire, 30mA (active) DSB423
DSB510
n/a
2-wire, 45mA (active) DSB378
DSB492
DSB511
n/a
Digital I/O DSB451 n/a
DSB524 n/a
Ethernet n/a n/a
LON ‡ DSB522 n/a
