PSS5000/CONF/804473/40 29 of 54
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
‡ Only one LON (TP/FT-10) interface (i.e. 1xKit422 or 1xDSB522) can be installed on each system.
When upgrading from CPB50x to CPB539, if a LON KIT422 is in use, it is necessary to include a DSB522
with the CPB539 to provide the LON functionality.
RS232 Tokheim special DSB357 n/a
9-pin with carrier detect DSB347 n/a
3-wire DSB457 n/a
Full handshake (modem
interface)
n/a DMB454
RS422 – DSB352 n/a
with echo canceling DSB475 n/a
RS485 – DSB453
DSB501
DMB506
(with grade select) DSB348 n/a
+ 5V supply DSB521 n/a
S & B Proprietary n/a DMB443
Interface Type
Modules
Addressable Non-addressable
