34 of 54 PSS5000/CONF/804473/40
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
Example 4 represents a situation similar to Example 3, but the daisy-chain oc-
curs inside the dual-sided dispenser. In this situation, the load on the HIM con-
nection is 2 devices.
3.9 Discontinued HIMs and Possible Replacements
List of HIMs no longer
available
If you already have HIMs in your system which do not appear in the Proto-
col/HIM lists, then it may be because they are no longer available. This list
contains those modules that have been discontinued and, where possible, the
name of a replacement HIM.
List of KITs no longer
available
If you already have a KIT in your system that does not appear in the Proto-
col/HIM lists, then it may be because it is no longer available. This list con-
tains those KITs that have been discontinued and, where possible, the name of
a replacement.
DSB modules DMB modules
Discontinued Replacement Discontinued Replacement
DSB337 DSB501 DMB354 DMB506
DSB338 DSB492 DMB359 DMB489
DSB339 DSB475 DMB417 none
DSB341 none DMB418 DMB507
DSB356 DSB517 DMB430 DMB512
DSB358 none DMB431 DMB507
DSB362 none DMB452 DMB512
DSB363 none DMB477 none
DSB415 DSB475
DSB408 DSB520
DSB433 none
DSB455 DSB476
DSB459 none
Discontinued Replacement
KIT422 DSB522
