22 of 54 PSS5000/CONF/804473/40
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
3.2 Tank Gauge System (TGS) Protocols and HIMs
List of TGS protocols and
associated HIMs
A complete list of the Tank Gauge System (TGS) protocols and the HIMs as-
sociated with the protocols currently supported by the PSS 5000 are shown in
the table below:
Note: Where Devices in Devices/Port refers to the maximum number of tank
gauges that are supported by the PSS per connected TGS. Normally, the
PSS supports only one TGS per port.
Protocols Interface Type HIM Stock No. Devices /Port
4Tech Fuelcom 501 RS232 (with carrier detect) DSB347 * 123240 8
RS232 (3-wire) DSB457 133845
B Control A (CMS) RS232 (with carrier detect) DSB347 * 123240 16
RS232 (3-wire) DSB457 133845
Egemin LGS2 RS232 (with carrier detect) DSB347 * 123240 8
RS232 (3-wire) DSB457 133845
Enraf STIC 867 (GPU) RS232 (with carrier detect) DSB347 * 123240 10
RS232 (3-wire) DSB457 133845
Fafnir Visy-Quick RS232 (with carrier detect) DSB347 * 123240 16
RS232 (3-wire) DSB457 133845
Fafnir UDP RS485, +5V supply DSB521 143437 16
Hectronic H-Protocol RS232 (with carrier detect) DSB347 * 123240 20
RS232 (3-wire) DSB457 133845
Hectronic HLS Protocol RS232 (with carrier detect) DSB347 123240 32
IFSF LON (TP/FT-10) ‡ DSB522 143576 16
‡ Only one LON (TP/FT-10) interface (i.e. 1xKit422 or 1xDSB522) can be in-
stalled on each system.
IGLA RS232 (with carrier detect) DSB347 * 123240 16
Lemis DC-400 RS485 DSB453 133768 16
MTS RS232 (with carrier detect) DSB347 * 123240 16
Petrovend4 RS232 (with carrier detect) DSB347 * 123240 32
RS232 (3-wire) DSB457 133845
Sense PMP RS232 (with carrier detect) DSB347 123240 32
Struna-M RS232 (with carrier detect) DSB347 * 123240 16
RS232 (3-wire) DSB457 133845
Struna + RS485 DSB453 133768 64
DSB501 142012
Veeder-Root RS232 (with carrier detect) DSB347 * 123240 16
RS232 (3-wire) DSB457 133845
