PSS5000/CONF/804473/40 31 of 54
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
DSB347 123240 1 1 1 RS232 (with carrier detect)
800212/--
800322/--
800345/--
800520/--
800696/--
802303/--
802458/--
802494/--
DSB348 123789 2
P
2
2 RS485 (grade select)
800403/--
DSB352 125775 4 1 2 RS422
800232/--
800434/--
802397/--
DSB357 126879 1 1 1 RS232
800155/--
DSB378 129251 4 4 2 Current Loop, 2-wire, 45mA (act)
800440/--
DSB411 128576 1 1 1 Current Loop, 4-wire, 10/20mA
800539/--
802798/--
803686/--
DSB416 129767 4 1 2 Current Loop, 4-wire, 10/20mA
(act.)
800190/--
802566/--
802567/--
803304/--
DSB423 130250 4
4
2
2 Current Loop, 2-wire, 30mA (act.)
802658/--
DSB451 133765 8 1 2 (8 channel pump light alarm)
802225/--
803456/--
804370/--
DSB453 133768 4
P
2
2 RS485
802190/--
802800/--
803455/--
DSB457 133845 4 1 2 RS232 (3-wire)
802222/--
DSB461 134791 4 1 2 Current Loop, 3-wire, 20mA (act.)
802457/--
DSB469 137734 – – 2 (Memory module)
803215/--
HIM Stock No.
No. of
connectors
Max. no. of
devices/connection
Width
(in module units)
Interface type
Drawings
/<mod.no.>/indr/
