PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
5 PSS 5000 Accessories List
Cables for the PSS The cables required to make the necessary connections associated with the
PSS 5000 are listed in the table below:
Cable Description Stock Number
Doms Standard cables
Standard cables For new PSS 5000 configurations, Doms
supplies correct cable types and lengths
for HIMs installed.
DSB cables
DSB No.23 (DSB universal), 80mm 126678
DSB No.33 short, 200mm 135694
DSB No.34 medium, 430mm 135695
DSB No.35 long, 630mm 135696
DMB cables
DMB No. 26 DMB (Universal), 50mm 126681
DMB No.36 short, 180mm 135697
DMB No.37 medium, 280mm 135698
DMB No.38 long, 480mm 135699
DSMB No.41, DSMB short, 230mm 138492
DSMB No.39, DSMB long, 710mm 135700
Internal LON, 50mm 139335
External RJ45 Ethernet (X-cable), 5m 136338
External RJ45 Ethernet (patch), 1m 134958
External RJ45 Ethernet (patch), 2m 134959
External RJ45 Ethernet (patch), 5m 133598
External 9P Service, null-modem, 3m
(PSS to PC)
135900
External 9P Service, null-modem, 5m
(PSS to PC)
136452
Cable Relief 14mm 135788
