30 of 54 PSS5000/CONF/804473/40
PSS 5000 – Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
3.8 HIM Details and Interface Types
List of HIMs with
hardware details and
interfaces
A complete list of HIMs and the interface types associated with each HIM is
shown in the table below:
Note: The maximum number of devices supported by the connection between
the DMB port on the CPU board and the DMB module(s) is 16.
Note: The maximum number of devices supported by the connection between
the DSB port on the CPU board and the DSB module(s) is dependent on
the protocol (see Devices/Port in the Protocols and HIMs tables).
Note: The hardware configuration of dispensers with multi-point fuelling
points affect the number of HIM connections required by the fuelling
point. See ‘Hardware configurations and interface connectivity’ on
page 33.
HIM Stock No.
No. of
connectors
Max. no. of
devices/connection
Width
(in module units)
Interface type
Drawings
/<mod.no.>/indr/
DCB modules
DCB449 133319 16 – 2
LON (TP/FT-10)
800673/--
DMB modules
DMB425 130742 4 1 2 Current Loop, 2-wire, 20mA (act.)
800043/--
DMB426 130745 4 1 2 4-wire 24V/50mA (act.)
802793/--
DMB443 132060 4 1 2 S & B Proprietary
802794/--
DMB450 133395 4 1 2 Current Loop, 4-wire, 10mA (act.)
800678/--
DMB454 133771 1 1 2 RS232 (modem interface)
802187/--
DMB489 139024 8 1 2 Current Loop, 2-wire 12V/25mA
(act.)
803593/--
DMB506 142292 4 1 2 RS485
804490/--
DMB507 142346 8 1 2 Current Loop, 2-wire, 20mA (pas)
804523/--
DMB512 142546 4 1 2 4-wire, Diff. Interface with auto-
watch
804644/--
DMB514 143076 8 1 2 2-wire, (act.)
804840/--
DSB modules
DSB340 121964 1
P
2
1 2-wire C-bus
800216/--
