PSS5000/CONF/804473/40
PSS 5000
–
Hardware Configuration Guide
Selecting the CPU Board and Interface Modules
Prowalco Remote Tagging
800320/--
DSB492
803807
/--
DSB503
804432/--
DSB511
804598/--
Tokheim DAC MPA V5
803392/--
n/a
n/a
Tokheim Pump Tag
8043
48/--
DSB520
804933/--
Wayne CL Terminal
803594/--
DSB475
80
2976/--
Wayne CL/EPS-42 Terminal
804814/--
DSB475
802976/--
Protocols
Interface Notes
/protocol/itno/
HIMs
Drawings
/<
mod. no.
>/indr/
45
47
