19 TECHNICAL DATA
EVOLUTION EV 30 FDX EV 40 FDX
N. of cast iron elements - 3 4
condensation
Boiler type -
heating + DHW tank
Heating input kW 29,3 40,5
Heating output kW 28,7 39,7
DHW tank capacity Lts. 130
DHW production in 10 min. ∆t=30ºC Lts. 321
DHW production in 1 hour ∆t = 30ºC Lts. 846
Recover time from 35 to 58 ºC min. 8
Heating temperature range ºC 30-85
DHW maximum temperature ºC 60
Heating security maximum temperature ºC 110
Heating security maximum pressure bar 3
DHW maximum temperature bar 7
Heating expansion vessel capacity Lts 8 12
Boiler water capacity Lts 19,2 23,2
Water pressure drop mca 0,3 0,4
Flue gases temperature ºC 67 83
Flue gases volume Lts 11,4 17,5
Flue gases flow Kg/s 0,0132 0,0186
Flue gases pressure drop mmH
2
O 2,0 2,1
CO emisions level mg/kWh 58 52
NOx emisions level mg/kWh 94,5 81,7
NOx class (EN 303-2) - 3
Combustion chamber lenght mm 300 400
Combustion chamber type - wet, three smoke steps
Burner model Domestic - D-3 D-4
Burner type - ON/OFF
Electric power - ~220-230 V - 50 Hz - 200 W
Weight Kg 265 285
N. of stars (92/42/CEE Directive) -

