Evolution FDX
4
3 INSTALLATION INSTRUCTIONS
The boiler has to be installed by personnel authorized by the Department of Industry in
accordance with the regulations and normative in force on this matter. Notwithstanding, it will be
necessary to comply with the following recommendations when installing the boiler:
3.1 Location
The boiler is to be installed into a sufficiently ventilated site. It will be essential to provide
access through one side of the boiler for maintenance tasks.
3.2 Hydraulic installation
The hydraulic installation should be made by qualified personnel staff. The installation
standards are to be complied with, although the following recommendations should be taken
into account:
- A thorough interior cleaning of the equipment piping is to be performed prior to the
switching on of the boiler.
- It is recommended that cut-off valves be interspersed between the equipment piping and
the boiler, in order to simplify the maintenance tasks.
- A minimum pressure of DHW of 0.5 bar is to be applied.
- It will be indispensable to drive the exit of condensed to a drainage, since the boiler
Evolution is a condensation boiler and the quantity of generated water can be big. Also,
before starting the boiler, it is recommended to fill the exit tube-siphon of condensed
water, with the purpose of garnishing the exit of smoke per it.
3.3 Electrical connection
The boiler is ready to be connected at 220 V 50 Hz on plugs 1 and 2 of the terminal strip J1
(see Electrical Connection Diagram). Do not forget to do grounding.
In addition, the boiler is provided with two terminals J5 for the room thermostat connection
(see Electrical Connection Diagram). For that, the bridge joining both terminals is to be
removed and the room thermostat is to be connected there.
3.4 Oil installation
The model Evolution is supplied with an oil burner Domestic (4) (see the model in the
Technical Data). For a correct oil line installation proceed in accordance with the burner
instructions enclosed in this manual (see Burner). The oil line installation and the start up
operation of the burner has to be carried out by qualified personnel staff.
3.5 Combustion products exhaustion
The installation of exhaustion of the products of combustion has to be carried out by qualified
personnel staff and it will fulfill the requirements demanded in the legislation and effective
regulatory schemes.
