C3725 - Horton Double Key Switch Assy
Will work but diodes will have to be cut and the nameplate will have to be changed. The 2 Way
Automatic and O are backwards. The One Way, Partial open, and Hold Open work properly.
Installation Manual
DC One V3
321 VZ County Road 4500 · Ben Wheeler, TX 75754 · Phone: 800.437.3667 · Fax: 800.356.8858 · DoorControlsUSA.com
17
Rev050819
