Power Train Disassembly & Assembly
9. Apply axle lubricant on the inside surfaces of both
case halves, spider (cross), thrust washers, side
gears and differential pinions.
10. Place the flange case half on a bench, ring gear
teeth toward top.
11. Install one thrust washer and side gear into the
flange case half.
12. Install the spider (cross), differential pinions and
thrust washers into the flange case half.
13. Install the second side gear and thrust washer
over spider and differential pinions.
14. Place the plain half of the differential case over
the flange half and gears. Rotate the plain half as
needed to align the match marks.
30
