022-00029AE Operation and Maintenance Manual Safety 1-9
When performing maintenance on the pilot control system, the hydraulic pressure in the system must be
released as describe in “Handling of Accumulator” on page 4-52.
5. KEEP OUT OF STEERING TURN AREA (4190-1992, 190-00120)
6. WARNING FOR HIGH TEMPERATURE HYDRAULIC OIL (2190-2529, 190-00097)
IMPORTANT
Refer to Shop Manual for service procedures. Do not release any pilot lines until pressure within
accumulator has been released.
DANGER!
Keep out of steering turn area.
WARNING!
HYDRAULIC OIL
To prevent hot oil from spurting out:
• Turn engine off.
• Allow oil to cool.
• Slowly loosen cap to relieve
pressure before removing.
AMO0410L
ACO1410L
To Next Page
