022-00029AE Operation and Maintenance Manual Operating Controls 2-7
3. COMBINATION SWITCH LEVER
A. Left Side Directional Switch -
Pushing lever forward, activates left
outside directional lights and
directional indicator light on
instrument panel.
B. Right Side Directional Switch -
Pulling lever back, activates right
outside directional lights and
directional indicator light on
instrument panel.
NOTE: When a turn is completed the
lever automatically returns to
"NEUTRAL" position. Should it
not, it can be manually
returned.
NOTE: Turn signals will function with starter switch in "OFF" position.
C. Window Washer Switch - When the outside area of the lever is pressed, it activates the washer
pump and sprays fluid on the windshield. (Only while being pressed.)
D. Horn Button - The center button on end of lever activates horn. (Only while being pressed.)
E. Wiper Switch - Activates wipers when outside area of lever is rotated.
J: Intermittent Mode - wipes every 5 seconds.
0: Stop (Off)
I: Normal Speed Mode
II: High Speed Mode
CAUTION!
The washer pump can be damaged if it is activated while there is no fluid in the tank.
The fluid level should be regularly checked and refilled if necessary.
Using soap or other solvents instead of the recommended washer fluid may damage
the wiper blades and the paint finish.
Only use recommended washer fluid or equivalent.
Figure 6
E
A
B
C
D
AHO0920L
Figure 7
