Harness Connector Locations
P1: 40 pin connector located on WEDGE controller
J02: 48 pin connector located on engine ECM
J5: 9 pin connector for WEDGE RS232 communication, located near WEDGE controller
P4/J4: 12 pin connector located at back of control panel
P2: 3 pin connector for termination resistor on J1939
CAN BUSS near WEDGE controller
P3: 3 pin connector for termination resistor on J1939
CAN BUSS near engine ECM
C11: 9 pin connector for engine ECM service tool, located near engine ECM
C07: 3 pin connector for auxiliary power that connects to C02 on engine harness, located on
engine
C18: 3 pin connector for intake heater control that connects to C03 on engine harness, located on
engine
P10/J10: 6 pin connector for various options, located near airend
P7/J7: 2 pin connector for Full Gauge option power, located behind control panel
P8/J8: 2 pin connector for Air Filter Restriction option, located near lift bail
P12/J12: 2 pin connector for IQ Filter Restriction option, located near lift bail
