Doosan P425CWJD - Page 93


Book: 23227143 (8-24-2010) Rev CPage91
Electrical Parts List
Reference
Designator
Description Part Number
RT1, RT2 Thermistor Temperature Sensor 23294820
PT1 0-500 psig Pressure Transducer 54765946
PT2 0-100 psig Pressure Transducer 36920825
S1 Ignition Switch 22127385
S1 Replacement Knob Assembly 22134118
S2 Service Air Switch 22054076
S15 Display Scroll Push Button 54475777
L1 Solenoid Valve 24VDC NC 36840841
L2
Solenoid Valve 24VDC NC
Model: P600WJD (7/170), HP450 (10/125),
VHP400WJD (14/115)
36840841
K1, K2 Relay 100 Amp 24VDC SPST 36853521
U1 Fuel Level Sender/Shutdown Sensor 54731427
TR1, TR2 J1939 CAN Terminating Resistor 23366784
F1, F2 Blade Fuse 20 Amp 36792083
F3 Blade Fuse 40 Amp 22986962
D1
Diode
D2 only on Model: P600WJD (7/170), HP450 (10/125),
VHP400WJD (14/115)
35376169
D2
Diode
Model: P600WJD (7/170), HP450 (10/125),
VHP400WJD (14/115)
35376169
M1 Hourmeter 24VDC 22054175
M2 Fuel Level Gauge 22692602
M3 4 in 1 Gauge Assembly (optional) 22255046
M4 Tachometer 24 VDC (optional) 22055883
M4 Replacement Resistor Board 24VDC 22271779
M5 Pressure Gauge 0-250 psi 36891216
M2, M3, M4, M5 Replacement Bulb 28VDC 22137426
DS1,DS2 Module 2 Light Warning 22172423
DS3 Wait To Start Light 22050553
RP1 Pressure Sender 0-150 psi (optional) 36870608
RT3 Temperature Sender 0-300
o
F (optional) 35367218
RT4 Temperature Sender 0-300
o
F (optional) 35372457
S16, S17 Air Filter Vacuum Switch NO (optional) 36847838
S18 Differential Pressure Indicator 25 psi (optional) 36899615
WEDGE Controller 22173579
Battery Positive Cable 35583582
Battery Negative Cable 35587088
Battery Terminal Jumper 35128982
Frame Ground Strap
Model: P425WJD (7/120), XP375WJD (9/110),
HP350WJD (10/105), & (14/85)
35578194
Frame Ground Strap
Model: P600WJD (7/170), HP450 (10/125),
VHP400WJD (14/115)
36783488
Chassis Harness
Model: P425WJD (7/120), XP375WJD (9/110),
HP350WJD (10/105), & (14/85)
22969554
