DORAN MODEL 8000
OPERATING AND SERVICE MANUAL
MAN0002-42 of 33
10
*30. 30000 lb x 10 lb 5 lb 20000 lb x 2 lb
13600 kg x 5 kg 2 kg 9100 kg x 1 kg
480000 oz x 200 oz 100 oz 32000lb x 50 oz
50. 50000 lb x 20 lb 10 lb 5 lb
22700 kg x 10 kg 5 kg 2 kg
800000 oz x 500 oz 200 oz 100 oz
75. 75000 lb x 50 lb 20 lb 10 lb
34000 kg x 20 kg 10 kg 5 kg
100. 100000 lb x 50 lb 20 lb 10 lb
45000 kg x 20 kg 10 kg 5 kg
*120. 120000 lb x 50 lb 20 lb 10000 lb x 10 lb
54400 kg x 20 kg 10 kg 45000 kg x 5 kg
"Scale Capacity" defines the capacity that the display will read out. See Section 3.4.10
for information on the selection of the total displayed graduations for the resolution
displayed with the selected capacity. It is used to match the scale indicator to the scale
platform.
In most cases, the factory has already selected the proper capacity to match the scale
platform that is supplied with the indicator. Should it be necessary to change the
capacity of the indicator, make sure that the proper capacity label from the label sheet
provided is inserted into the capacity window of the faceplate of the indicator.
Refer to Section 6 on Calibrating the 8000 to make sure that the scale is properly
calibrated after changing the capacity.
Refer to Section 3.4.8 Operating Mode for legal for trade restrictions.
3.4.7 Unit On Timer (tdy)
Function Option Description
tdy on on/off thru "ON/ZERO"
.5 30 second "On Timer"
1.0 1 minute "
1.5 1.5 minute "
2.0 2 minute "
3.0 3 minute "
5.0 5 minute "
10.0 10 minute "
30.0 30 minute "
The "On Timer" governs the amount of time the 8000 stays on after ON/RESTART is
pressed. The electronics in the 8000 sense activity on the scale platform - when there
is no activity on the platform within the time programmed for the "On Timer", the 8000
will turn itself off. Each time there is activity (motion) on the scale platform or any
pushbutton activity before the scale turns off, the "On Timer" is reset for its full time
period.
Remember that the 8000 provides up to 40 hours of continuous operation on a 4-hour
recharge (except for the 8000MIS model).
