10. Configuration for SSP/DLP printer
When print format 6 is selected the output from the serial port will be as follows:
|l|FR”LF1”|l?| weight data |I| units |l| gross/net|l|P1|l
Command Function Description
l line feed (lower case L) Must precede any commands to the printer.
FR Form Retrieve Tells the printer which form to use.
“LF1” Label format name Label format name for Print Format 6.
l line feed
? Call for variables Tells the printer to expect variable data.
l line feed
Weight Data send weight data Six character field, including decimal point.
Leading spaces are sent as spaces.
l line feed
Units send current units Three character field for weight units: lb, kg, oz.
l line feed
Gross/net Send weighing mode of the
scale
Three character field to indicate Gross or Net
mode of the scale.
l line feed
P1 print 1 label Tells printer to print 1 copy of label.
l line feed
The software required is: M8040 Revision 4.2 or M8001 Rev. 4.2 or higher
8000 Configuration:
1. Baud Rate Selection: Set menu 3.4.3 b.r. to 960 for 9600 baud.
2. Print format selection: Set menu 3.4.16 Pft to 6 for SSP print format.
3. Push Button Operation: Set menu 3.4.9 P.b. to the desired print operation.
4. Data Bits and Parity: Set menu 3.4.11 d.b.P. to 8 n. 8 data bits, no parity.
Note: M8040 Rev. 4.2 software has the following factory defaults:
Menu Function Setting Description
3.4.3 Baud Rate 960 9600
3.4.9 Pushbutton Operation CPd Conv & Print w/xmit prompt
3.4.12 Convert Select LGO lbs,kg,oz conversion**
3.4.16 Print Format 6 SSP/DLP print format
** Note: The printer cannot print lbs-oz readings.
Printer Connection To 8000:
Connect the printer cable ( SUB0221 ) to TB1 on the 8000 main board.
Red wire to TB1 pin 3.
White wire to TB1 pin 2.
