DORAN MODEL 8000
OPERATING AND SERVICE MANUAL
MAN0002-42 of 33
5
3.2 ENTERING THE "USER SET-UP MENU"
1. Remove the small access panel on the rear of the scale indicator by removing the
two hex screws holding the panel in place.
2. Flip SW1 located on the PCB inside the access port (red toggle handle switch).
3. The scale display will display the message AUG --.
3.3 TO SET OR REVIEW PARAMETER SETTINGS
Programming the 8000 is done by pressing the TARE and ZERO buttons on the front
panel of the indicator.
To change or review parameter settings, simply step through each parameter by
pressing ZERO and select the desired option by pressing TARE.
1. Press ‘ZERO’ to increment the parameter shown on the left of the display.
2. Press TARE to increment the option shown on the right of the display. Each
parameter has several options to select from that affect scale operation.
3. Flip SW1 back to its original position (inboard) to return to normal operation. This
can be done at any point in the set up menu.
4. Replace the access cover on the back of the unit to maintain its water resistant and
dust-tight integrity.
Configuration is permanently saved in a nonvolatile EEPROM (Electronically
Erasable/Programmable Read-Only Memory).
3.3.1 Table of User Setup Parameters Default settings are in bold.
Parameter Description Options
AVG Digital Averaging
A1,1,2,4,8,16,A2
AZT Auto Zero Tracking
.5,1,3,OFF
b.r. Baud Rate
960,480,240,120,30
d.o. Data Output Mode
tod,Cnt,AP1,AP2,AP3,L.O.d.
S.U. Start up unit
Lb,kg,oz,L O
CAP Scale Capacity 1.3 thru 120
tdy Unit On Timer
.5,1.0,1.5,2.0,3.0,5.0,10.0,30.0
oP Operating Mode
Std,44,CAn
P.b. Push Button Operation
non,C,P,CP,Pd,CPd
CtS Total Number of Graduations
3,6,10
d.b.p Data Bits and Parity
8n,7n,7O,7E
hSh Clear to Send Enable
OFF,ON
CSL Convert Select Operation
CA,LGO,LG,LO,GO
SLU Metric Display Unit
kg,g
S.U.0 Start Up Zero
--0,CL0,Pb0
MA Motion Aperature
1,3,5
PFt Print Format
1,2,3,4,5,6
To Next Page
