DORAN MODEL 8000
OPERATING AND SERVICE MANUAL
MAN0002-42 of 33
7
Automatic Zero Tracking is used to compensate for small deviations from zero caused
by such things as slight air currents or material left on the scale platform.
Automatic Zero Tracking will measure this deviation every scale update, and if it is
within the specified range of scale divisions, it will automatically re-zero the scale.
Adjust the Zero Track Aperture so that it best fits your application.
If you are working with minute weights that are near zero, it is advisable to turn
Automatic Zero Tracking off, as it may interfere with the weighments.
When set for a Legal for Trade operating mode ("44" or "CAN"), only the "off" or ".5"
option is allowed for this parameter.
3.4.3 Baud Rate Selection (b.r.) See Section 5 for more information
Function Option Description
b.r. 960 9600 baud
480 4800 baud
240 2400 baud
120 1200 baud
30 300 baud
3.4.4 Serial Data Output Mode (d.o.) See Section 5 for a detailed explanation
Function Option
Description
d.o. tod Transmit on Demand
Cnt Continuous Transmission
AP1 Auto Print 1
AP2 Auto Print 2
AP3 Auto Print 3
L.O.d. Latch on Demand
3.4.5 Start-Up Unit (S.U.)
Function Option
Description
S.U. Lb Start-up in "lb
hg Start-up in "kg or g"
oz Start-up in "oz"
*L O Start-up in "lb & oz"
The Start-Up Unit is the weight display unit that the 8000 displays in when the scale is
turned on. Select the unit that is most frequently used as your start-up unit.
The lb & oz unit can only be selected for 1, 3, 5, 10, 15, 20, 30, 60, 100, 120, 150, 200,
and 300 pound capacities for 3000 displayed graduations and 3, 5, 10, 20, 30, 60, 100,
200, 300, 500, and 600 pound capacities for 6000 displayed graduations.
Note: When the operating mode of the 8000 (see below) is set to HB44 or CAN (Legal
for Trade), the "lb & oz" weight display mode will not function since it is not
recognized as a legal for trade display unit.
