Section 6. Data Communications
USB Communications Port Option
The indicator is equipped with a USB C communications and charging port. The
USB C connection is located on the back of the indicator. Connect the EMR
Communication Module to the scale by plugging into the scale’s USB C port.
Double sided foam tape is provided to adhere the module to a convenient
location. It is recommended to adhere the module to the rear and top of the
column if available. If a remote indicator, mount to the rear or bottom of the
indicator. Be sure that the cable connection is not tight which could pull the USB
C connector from the rear of the indicator.
EMR Communication
Option Module
To Next Page
