Dorma ED 100 Mounting And Commissioning Instructions

1. General information
Keep the documents in a safe place and hand them over to
the new facility drive if you transfer the system.
Symbols used in these instructions
 REMARK A remark draws attention to important
information which may make work
easier for you.
 NOTE A note warns of potential damage to
the device and explains how it can be
avoided.
ATTENTION This symbol points out dangers which
may result in personal injury or even
death.
 Unless specified otherwise,
all dimensions are given in mm.
“Translation of the original instructions”
Contents
Page
1. General information ................................................................................................................2
2. Safety ....................................................................................................................................3
3. Product description .................................................................................................................4
4. Preparing for installation..........................................................................................................9
5. Installing the drive unit .......................................................................................................... 18
6. Connecting the accessories ....................................................................................................29
7. Commissioning .....................................................................................................................31
8. Installing Upgrade Cards .......................................................................................................32
9. Parameterization/service ........................................................................................................34
10. Diagnosis/troubleshooting ......................................................................................................41
11. Error messages .....................................................................................................................43
ED 100, ED 250
—
2

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
