Dorma ED 100 - Page 14

45
45
150
10695
245
B
D
C
120 100120120
50
32
63
A
33
Bottom edge of frame
Bottom edge of frame
ED 100 = 0 mm – 300 mm
ED 250 = 0 mm – 500 mm
Space for cable inlet
Installation on opposite hinge side with arm
Axle extension ED 100 ED 250 A B C D
Standard (9 mm)
19 mm 51 mm 9 mm 42 mm
20 mm
39 mm 71 mm 29 mm 62 mm
30 mm
49 mm 81 mm 39 mm 72 mm
60 mm
79 mm 111 mm 69 mm 102 mm
90 mm ---
109 mm 141 mm 99 mm 132 mm
Ø 6.6
ED 100, ED 250
—
14 DORMA
