Dorma ED 100 - Page 13

45
32
45
150
10612012095
451
145
B
D
A
C
120 100
35
63
Bottom edge of frame
Upper edge of door
Space for cable inlet
Installation on opposite hinge side of slide channel
Axle extension ED 100 ED 250 A B C D
Standard (9 mm)
15 mm 49 mm 6 mm 40 mm
20 mm
35 mm 69 mm 26 mm 60 mm
30 mm
45 mm 79 mm 36 mm 70 mm
60 mm
75 mm 109 mm 66 mm 100 mm
90 mm ---
105 mm 139 mm 96 mm 130 mm
Maximum lintel depth of 60 mm
 The maximum opening width is 95°.
 The axle adapter is installed rotated by 45°.
Not suitable for fire and smoke doors!
Ø 6.6
ED 100, ED 250
—
13DORMA
