(44)
SEE NOTE #5
(76)
3
REINFORCED.
(259)
10-3/16
(33)
1-5/16
20-3/8
(518)
(51)
2
5/16
(8)
WITH 870 ANGLE BRACKET
7. DOORS AND FRAMES MUST BE PROPERLY
6. MAXIMUM OPENING ANGLE 115°.
(321)
12-5/8
DOORS OR LABELED FIRE DOORS.
ATTACHMENT OF COMPONENTS ON COMPOSITE
4. CAUTION: SEX NUTS ARE RECOMMENDED FOR
TEMPLATE No. ED800-SP1 Rev.02/95
TOP JAMB INSTALLATION - (PUSH SIDE MOUNT)
ED800J
1-3/4
TWO (2) HOLES IN DOOR FOR ARM SHOE
FOR SEX NUTS USE 3/8" DRILL
FOR No.14 WOOD SCREWS USE 5/32" DRILL
FOR 1/4-20 MACHINE SCREWS USE No.7 DRILL
SIX (6) HOLES IN FRAME FOR BRACKET
FOR No. 14 WOOD SCREWS USE 5/32" DRILL
FOR 1/4-20 MACHINE SCREWS USE No.7 (0.201") DRILL
MOUNTING SURFACE.
5. ALWAYS LOCATE ARM SHOE FROM 870 BRACKET
2. DIMENSIONS ARE IN INCHES/(MM).
1. DO NOT SCALE DRAWING.
OF 4-1/2" WIDE HINGE, 3/4" OFFSET PIVOT,
C
NOTES:
3. LEFT HAND DOOR SHOWN.
(156)
6-1/8
08102710 05/07ED800-27
ED 800J x 870 ANGLE BRACKET - TOP JAMB INSTALLATION TEMPLATE
ED 800J x 870 ANGLE BRACKET x 831 ARM SHOE DROP PLATE
- TOP JAMB INSTALLATION TEMPLATE
1-1/4
(44)
(32)
3. LEFT HAND DOOR SHOWN.
NOTES:
C
OF 4-1/2" WIDE HINGE, 3/4" OFFSET PIVOT,
1. DO NOT SCALE DRAWING.
2. DIMENSIONS ARE IN INCHES/(MM).
5. ALWAYS LOCATE 830 PLATE FROM 870
BRACKET MOUNTING SURFACE.
FOR 1/4-20 MACHINE SCREWS USE No.7 (0.201") DRILL
FOR No. 14 WOOD SCREWS USE 5/32" DRILL
SIX (6) HOLES IN FRAME FOR BRACKET
FOR 1/4-20 MACHINE SCREWS USE No.7 DRILL
FOR No.14 WOOD SCREWS USE 5/32" DRILL
FOR SEX NUTS USE 3/8" DRILL
THREE (3) HOLES IN DOOR FOR PLATE
1-3/4
ED800J
TOP JAMB INSTALLATION - (PUSH SIDE MOUNT)
TEMPLATE No. ED800-SP3 Rev.08/95
4. CAUTION: SEX NUTS ARE RECOMMENDED FOR
ATTACHMENT OF COMPONENTS ON COMPOSITE
DOORS OR LABELED FIRE DOORS.
12-5/8
(321)
6. MAXIMUM OPENING ANGLE 115°.
7. DOORS AND FRAMES MUST BE PROPERLY
WITH 870 ANGLE BRACKET X 831 ARM SHOE DROP PLATE
(8)
5/16
2
(51)
(518)
20-3/8
1-5/16
(33)
10-3/16
(259)
REINFORCED.
3
(76)
SEE NOTE #5
1/2
(13)
7/8
(22)
