Dormakaba ED100 Owner's Manual

18
ED50/ED100/ED250 09-2021DL4616-011
dormakaba ED50/ED100/ED250 Owner's Manual
Overhead concealed header
Chapter 7
. Door signage, full energy power operated double egress swing doors
(ANSI/BHMA .)
Fig. 7.7.2 RH double egress, interior side
Swing side
Approach side
Fig. 7.7.3 RH double egress, exterior side
Swing side Approach side
Fig. 7.7.6 LH double egress, exterior side
Fig. 7.7.5 LH double egress, interior side
Fig. 7.7.1 OHC RH double egress
Fig. 7.7.4 OHC LH double egress
Swing sideApproach side
Swing sideApproach side
50” ± 12”
DD0739-010
AUTOMATIC
DOOR
DO NOT
ENTER
AUTOMATIC
DOOR
50” ± 12”
DD0739-010
AUTOMATIC
DOOR
DO NOT
ENTER
AUTOMATIC
DOOR
50” ± 12”
DD0739-010
AUTOMATIC
DOOR
DO NOT
ENTER
AUTOMATIC
DOOR
50” ± 12”
DD0739-010
AUTOMATIC
DOOR
DO NOT
ENTER
AUTOMATIC
DOOR
Swing side
Approach side Swing side
Approach side

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
