10
11
OPERA
TION
Use the corresponding mode control keys to select the required operation
mode. These keys provide an access to the most frequently used functions of
the device. Let’s consider them in brief.
ATTENTION! DURING IGNITION OF THE UV AND WHITE LAMPS, ALL
THE KEYS GET DISABLED. AN ACTIVE STATE OF THE KEYS IS RE-
COVERED AFTER IGNITION OF THE LAMPS HAS BEEN COMPLET-
ED.
1. TV key switches the source of the image appearing on the device
display. The image sources may be both device cameras (with zoom
1x and zoom 10x), and the external devices connected to connectors V1,
V2, IN.
1.1 short pressing of the TV key switches the modes of the image from the
device built-in cameras.
■ The first short pressing switches on a 10x zoom displaying. The
“Zoom 10x” message appears on the display for several seconds.
After the time has expired, the display restores the message about
the current illumination mode, for example, “IR”.
■ the second short pressing returns the image without zoom. The
“Zoom 1x” message appears on the display for several seconds.
After the time has expired, the display shows a restored message
about the current illumination mode, for example, “IR”.
■ Any further short pressing results in the same switching as after
the first pressing, the second one etc.
1.2 A long pressing of the TV key results in displaying an image from an
external video source (from input V1), the image is accompanied by the
“Video input V1” message appearing on the display for several sec -
onds. After the time has expired, there is displayed a message about the
current illumination mode set in the signal source (a video magnifier), for
example, “Video 1 IR”, connected to the given video input.
1.2a Any further short pressing of the TV key results in connection of
the display to video inputs V2 and IN.
UNIVERSAL COUNTERFEIT DETECTOR DORS 1300 UNIVERSAL COUNTERFEIT DETECTOR DORS 1300
■ The first short pressing switches on displaying from input V2
accompanied by the “Video input V2” message displayed for
several seconds. After the time has expired, there is displayed
a message about the current illumination mode set in the signal
source (a video magnifier), for example, “Video 2 UV”, connect-
ed to the given video input.
■ the second
short
pressing
switches on displaying from in-
put IN with the “Video input In” message displayed for sev-
eral seconds. After the time has expired, there is displayed the
“Video In” message.
■ the third short pressing results in returning to displaying from
input V1 which is accompanied by the “Video input V1” mes-
sage displayed for several seconds. After the time has expired,
there is a message displayed about the current illumination
mode set in the signal source (a video magnifier), for example,
“Video 1 IR” connected to the given video input.
■ Any further short pressing results in the same switching over
as after the first pressing, the second one etc.
1.2b to return to the image from the device built-in camera, it is
necessary to press the TV key once more for a long time.
2. DL key
controls switching on of the top oblique white light as well
as a combined illumination of the viewing table by white light and
transmitted IR light. The source of the top white light may be switched
on in the mode of switching of the incidence angle. Illumination of the
viewing table and an oblique white light do not switch on simultaneously.
■ The first pressing switches on illumination of the viewing table by white
light and transmitted IR light. There is displayed the
“TOP
White”
mes-
sage for several seconds. After the time has expired, there is a message
about the current illumination mode, i.e. “TOP White+IR”.
■ A result of next pressing is depended on current magnification mode:
а. No magnification (1х):
a mixed light consisted of top white light and IR light is switched on.
There is displayed the “TOP White” message for several seconds.
After the time has expired, there is a message about the current il-
lumination mode, i.e. “TOP White+IR”.
