SPECIFICATIONS & DIMENSIONS
Version D9WL3000 D9WL3000IE
Operating flow range:500l/h min.9m3/h max. [2.2-40US gpm]
Max. operating temperature: .............................40°C [104°F]
Operating pressure:
bars 0.3-8 0.5-8
psi 4.3-116 7.2-116
Externally adjustable dosing rate:
% 0.03 - 0.2 0.03 - 0.2
Ratio 1:3000 - 1:500 1:3000 - 1:500
Concentrated product injection rate:
Min. l/h - Max. l/h 0.15-18 0.15-18
US Fl. oz/min - MIN 0.08 0.08
US Fl. oz/min - MAX 10.14 10.14
Connection (NPT/BSP male gas fittings): .......... Ø40 x 49mm [1 1/2”]
Hydraulic motor capacity (every two clicks of the piston):
approx.1.7L [0.449US Gallons]
ATTENTION! The DOSATRON is not pre-set, please refer to the
paragraph on Adjusting the dosing (without pressure), page 35
DIMENSIONS
Diameter: cm [“] 17.55 [6 9/10] 17.55 [6 9/10]
Total height: cm [“] 67.82 [26 11/16] 67.82 [26 11/16]
Overall width: cm [“] 21.8 [8 1/2] 21.8 [8 1/2]
Weight: ± kg [lbs] 3.3 [7.3] 3.3 [7.3]
