FEET OPTIONS
If necessary, or if your DOSATRON cannot be fitted to the wall, the D9
DOSATRON range can be installed on feet using the 8EQ001 kit:
• Insert each foot in the corresponding holes on the bracket supplied with the
dosing pump and the bracket included in the kit
• Secure each foot using the 4 screws supplied.
• Insert the DOSATRON dovetails into each bracket fitted with 2 feet.
fig 26
