dosatron D9 - PACKAGING

/ 15
SPECIFICATIONS
Version D9WL2 D9WL5
Operatingflow range:500l/h min.9m3/h max. [2.2-40US gpm]
Max. operatingtemperature: .............................40°C [104°F]
Operatingpressure:
bars 0.3-8 0.5-8
psi 4.3-116 7.2-116
Externallyadjustabledosing rate:
% 0.2 - 2 1 - 5
Ratio 1:500 - 1:50 1:100 - 1:20
Concentrated product injection rate:
Min. l/h - Max. l/h 1-180 5-450
US Fl. oz/min - MIN 0.56 2.82
US Fl. oz/min - MAX 101.45 253.62
Connection(NPT/BSP male gas fittings): ....................... Ø40 x 49mm [1 1/
2”]
Hydraulic motor capacity(every two clicks of the piston):
approx.1.7L [0.449US Gallons]
ATTENTION! The DOSATRON is not pre-set, please refer to the
paragraph on Adjusting the dosing (without pressure), page 35
DIMENSIONS
Diameter:cm[”] 17.55[6 9/10] 17.55[6 9/10]
Total height:cm[”] 67.82[26 11/16] 67.82[26 11/16]
Overall width:cm[”] 21.8[8 1/2] 21.8[8 1/2]
Weight: ±kg[lbs] 3.3[7.3] 3.3[7.3]
PACKAGING
PACKAGE COMPOSITION:
1 DOSATRON/1 DOSATRON mounting bracket/1 suction hose for
concentrate/1 strainer/1 external injection kit for "IE" models/1 quick start
guide
PACKAGING DIMENSIONS:
67 x 22.5 x 20.5 cm [26 3/8” x 8 7/8” x 8 1/16”]
