Doyon LSB516 - Page 20

LMA-A REV.DOC 23/04/08
20
4. Remove the “spring pin” of the handle [picture E, F] and then the handle.
5. Remove the superior front cover [picture G] and the two back covers [picture H].
6. Loosen the belt stretcher [picture I] and take the belt off [picture J].
E F
G H
